Presto Smart POS partners

Unpairing your payment terminal

1. Press the green Enter button and the numerical button 3 at the same time

2. The option to unpair will appear on the payment terminal screen. Select Unpair and that’s it.


Unpairing your POS

1. Navigate to the Settings tab in your Abacus POS and select Payment

2. Select the UNPAIR option, and that’s it.


Please visit Abacus for more information.

1. Launch RetailTouch Point-of-Sale app
2. Login in to user
3. Click the EDIT tab
4. Click SETUP and hit OK on the alert window
5. Click the SETUP tab
6. Go to Device Setup > RetailTouch Shared Devices
7. Highlight EFTPOS PIN Pads and click on Add New
8. Select Westpac Group Settings and hit OK
9. Type the EFTPOS Address and hit SAVE
10. Then initiate pairing from POS and hit Pair button on the POS
11. Confirm the code matches on both POS and EFTPOS
12. Hit OK to dismiss the alert window saying pairing is successful
13. Close the pairing screen and all settings associated with it
14. Click the EDIT tab and click SETUP to go back to non-editing mode on the POS

Please visit ABS POS for more information.

1. Click the EDIT tab
2. Click SETUP and hit OK on the alert window
3. Click the SETUP tab
4. Go to Device Setup > RetailTouch Shared Devices
5. Highlight Westpac Group Settings under EFTPOS PIN Pads
6. Click Setup
7. Hit the unpair button
8. Close out all windows associated with the pairing/settings
9. Click the EDIT tab and click SETUP to go back to non-editing mode on the POS.

Please visit ABSPOS for more information.

1. Launch the Spice Payments Adaptor.
2. Go to EFTPOS tab.
3. Enter the POSID and EFTPOS Address.
4. Initiate the pairing from the EFTPOS terminal.
5. Click the Pair button from the Spice Payments Adaptor.
6. Accept the pairing code on the EFTPOS terminal.

Please visit AdvanceRetail for more information.

1. Launch the Spice Payments Adaptor.
2. Go to Settings tab.
3. Select Unpair.

Please visit AdvanceRetail for more information.

1. From the EFTPOS menu select Westpac EFTPOS settings
2. Enter a POS ID and EFTPOS address and click on save
3. Click Pair on the EFTPOS terminal
4. Click Pair on the Westpac EFTPOS settings screen
5. Accept both codes if they match.

Please visit Apparel 21 for more information.

1. From the EFTPOS menu select Westpac EFTPOS settings
2. Click on Unpair.


Please visit Apparel 21 for more information.

1. Log into the POS application
2. Click on Manager
3. Select Westpac Pairing
4. Enter valid EFTPOS Address, save and pair it.

Please visit ARZPOS for more information.

1. Log into the POS application
2. Click on Manager
3. Select Westpac Pairing
4. Click on Unpair button.

Please visit ARZPOS for more information.

1. Launch the POS.
2. In the Windows taskbar, right-click the Payment Agent program icon.
3. Enter IP address and POS ID and select Save.
4. Select Pair on the EFTPOS terminal and POS.

Please visit AUPOS Retail for more information.

1. Launch the POS.
2. In the Windows taskbar, right-click the Payment Agent program icon.
3. Select Unpair.

Please visit AUPOS Retail for more information.

1.    Launch the Spice Payments Adaptor.
2.   Go to EFTPOS tab.
3.   Enter the POSID and EFTPOS Address.
4.   Initiate the pairing from the EFTPOS terminal.
5.   Click the Pair button from the Spice Payments Adaptor.
6.   Accept the pairing code on the EFTPOS terminal.

Please visit Barcode for more information.

1.    Launch the Spice Payments Adaptor.
2.   Go to Settings tab.
3.   Select Unpair.

Please visit Barcode for more information.

1.    Go to UTILITIES
2.    Click Westpac Control Panel
3.    Type the POS ID and EFTPOS ADDRESS
4.    Click SAVE
5.    Click PAIR
6.    Once the confirmation code appears and confirmed as exact and the same with EFTPOS, hit YES IT MATCHES on the POS and YES on the EFTPOS Terminal
7.    Click OK on the POS and Complete Setup in EFTPOS

Please visit BizFlex for more information.

1.    Go to UTILITIES
2.    Click the UNPAIR button
3.    Click YES on the confirmation window
4.    Hit OK on the information window pop up

Please visit BizFlex for more information.

1. On the POS, select Settings.
2. Select Payment Settings.
3. Enter the EFTPOS S/N and enable Automatic EFTPOS Address.
4. Select Save.
5. Initiate pairing from the EFTPOS terminal and then from the POS.
6. Accept the pairing code on the EFTPOS terminal and POS.

Please visit Black Label Solutions for more information.

1. On the POS, select Settings.
2. Select Payment Settings.
3. Select Unpair.

Please visit Black Label Solutions for more information.

1. Log into POS
2. Under File select EFTPOS terminal setup
3. Enter IP address displayed on EFTPOS terminal into EFTPOS address field on POS
4. Press Pair on the terminal and on POS
5. Confirm code on Terminal and POS
6. Press OKAY to confirm pairing.

Please visit BLUETILL for more information.

1. Log into POS
2. Under File select EFTPOS terminal setup
3. Select Unpair
4. On the terminal press enter + 3 to open unpairing menu
5. Select Unpair.

Please visit BLUETILL for more information.

1. Log into the POS application
2. Click on the Exit, etc button in the bottom left corner, and then select Close > Go Management
3. Click on the System Setting button in the left hand navigation
4. Click on the Customising option
5. Click on the Device tab
6. In the Device tab under the EFTPOS section click on the Setting button
7. On the Westpac Group Settings screen enter a valid POS ID and EFTPOS Address and click on the save button
8. Click on the Pair button on the EFTPOS terminal
9. Click on the Pair button on the Westpac Group settings screen
10. Confirm codes on both the POS and the EFTPOS terminal if they match
11. Click on the Close button to exit the Westpac Group settings
12. Click the Save button on the Device tab
13. Click on the POS button to return to the main POS screen.

Please visit Bsmarter for more information.

1. Log into the POS application
2. Click on on the Exit, etc button in the bottom left corner, and then select Close > Go Management
3. Click on the System Setting button in the left hand navigation
4. Click on the Customising option
5. Click on the Device tab
6. In the Device tab under the EFTPOS section click on the Setting button
7. On the Westpac Group Settings screen enter a valid POS ID and EFTPOS Address and click on the save button
8. Click on the Unpair button on the Westpac Group settings screen.


Please visit Bsmarter.com.au or more information.

1. Go to Settings
2. Go to Hardware
3. You should find a WESTPAC GROUP PAYMENT section
4. Hit Connect WESTPAC GROUP EFTPOS
5. Type the POS Name and the EFTPOS IP Address
6. Hit SAVE
7. Initiate the pairing from the Terminal and hit Pair with EFTPOS in the POS App

Please visit ClickPOS Application for more information.

1. Go to Settings
2. Go to Hardware
3. You should find a WESTPAC GROUP PAYMENT section
4. Hit Connect WESTPAC GROUP EFTPOS
5. Hit Unpair

Please visit ClickPOS Application for more information.

1. Go to Maintain > System Admin > Intelligent Functions > Merchant Setup
2. Type the POS ID & Terminal Serial Number (available on Presto Eftpos Terminal)
3. Select Automatic (Test Mode should be off/deselected)
4. Click SAVE
5. EFTPOS Address field should populate with the IP Address
6. Initiate pairing via Presto EFTPOS Terminal
7. Click the PAIR button on the POS
8. Confirm on both POS and EFTPOS that code matches
9. Click OKAY on POS
10. Press Complete Setup on EFTPOS.

Please visit ClickPOS Browser for more information.

1. Go to Maintain > System Admin > Intelligent Functions > Merchant Setup
2. Click Unpair
3. Click Okay

Please visit ClickPOS Browser for more information.

1. On the main screen click on the Pair Eftpos button
2. Enter the IP address and POS ID, then click on save
3. Click Pair on the Eftpos terminal
4. Click Pair on the Pair with Eftpos popup
5. Accept codes on both ends if they match.


Please visit CloudHQ for more information.

1. On the main screen click on the Pair Eftpos button
2. Click on the Unpair button.


Please visit CloudHQ for more information.

1. Launch the Spice Payments Adaptor.
2. Go to EFTPOS tab.
3. Enter the POSID and EFTPOS Address.
4. Initiate the pairing from the EFTPOS terminal.
5. Click the Pair button from the Spice Payments Adaptor.
6. Accept the pairing code on the EFTPOS terminal.

Please visit Computerlink for more information.

1. Launch the Spice Payments Adaptor.
2. Go to Settings tab.
3. Select Unpair.

Please visit Computerlink for more information.

1. Select the Functions tab.
2. Select Westpac Configuration.
3. Type the POS ID and S/N (with Auto IP Address feature enabled).
4. Select Save.
5. Initiate pairing from the EFTPOS terminal.
6. Select Pair.

Please visit Coyote Software NightOwl for more information.

1. Select the Functions tab.
2. Select Westpac Configuration.
3. Select Unpair.

Please visit Coyote Software NightOwl for more information.

1. Press Menu icon in the top let corner (Hamburger icon)
2. Select Settings from the Menu options
3. Select Peripherals tab in the top section under Settings
4. Toggle Enable Westpac Group Payments. This should display a Settings button and various other options, Select Settings
5. Enter POS ID, Eftpos Serial Number and tick Automatic for Eftpos Address
6. Press Save then start the pairing process. Press Pair with POS on terminal then Pair on the POS
7. Accept codes on the terminal and POS if matching
8. The pairing process is complete

Please visit Eposnow for more information.

1. Press Menu icon in the top let corner (Hamburger icon)
2. Select Settings from the Menu options
3. Select Peripherals tab in the top section under Settings
4. Select Settings under Westpac Group Payments
5. Press Unpair.


Please visit Eposnow for more information.

1. Launch the Spice Adaptor
2. Go to EFTPOS tab
3. Enter a valid POSID and EFTPOS Address
4. Initiate the pairing from the EFTPOS terminal
5. Click the Pair button from the Spice Adaptor
6. Accept the pairing code on the EFTPOS terminal
7. Pairing Successful.

Please visit Esuite for more information.

1. Launch the Spice Adaptor
2. Go to Settings tab
3. Select "Unpair"
4. Unpairing Successful

Please visit Esuite for more information.

1. Launch the Spice Payments Adaptor.
2. Go to EFTPOS tab.
3. Enter the POSID and EFTPOS Address.
4. Initiate the pairing from the EFTPOS terminal.
5. Click the Pair button from the Spice Payments Adaptor.
6. Accept the pairing code on the EFTPOS terminal.

Please visit Fedelta POS for more information.

1. Launch the Spice Payments Adaptor.
2. Go to Settings tab.
3. Select Unpair.

Please visit Fedelta POS for more information.

1. Select the Westpac Settings icon on the desktop.
2. Enter the POSID and EFTPOS Address and select Save.
3. Initiate pairing from the EFTPOS terminal and then from the POS.
4. Accept the pairing code.
5. Close the Westpac Settings application and launch the POS.

Please visit Futura4Retail for more information.

1. Exit Futura4POS
2. Click on the Westpac Settings icon on the desktop
3. Click Unpair.

Please visit Futura4Retail for more information.

1. Click on the PCPOS icon on the desktop
2. Hit Westpac Settings (with the ERS logo on it)
3. Type the POS ID and EFTPOS Address
4. Hit SAVE
5. Initiate the pairing process on the Terminal6
6. Hit the Pair button on the POS
7. Confirm the code on POS and Terminal
8. Hit Close.

Please visit FuturaERS for more information.

1. Go to Westpac Settings
2. Hit Unpair
3. Hit Close.

Please visit FuturaERS for more information.

1. Make sure you are in the home screen
2. Select EFTPOS DIAGS
3. Select Westpac Group Settings
4. Enter POSID & IP Address and click SAVE
5. Select Pair
6. Accept code on terminal and POS if correct
7. Once paired, press Close.

Please visit FutureNet for more information.

1. Make sure you are in the home screen
2. Select EFTPOS DIAGS
3. Select Westpac Group Settings
4. Select unpair.

Please visit FutureNet for more information.

1. Click on Show Menu in the bottom right of the screen. A menu will now appear at the top of screen.

2. From the EFTPOS menu select EFTPOS Initialisation.

3. Enter an EFTPOS address and click on save.

4. Click Pair on the EFTPOS terminal.

5. Click Pair on the EFTPOS Westpac settings screen.

6. Accept both codes if they match.


Please visit Harmony for more information.

1. From the EFTPOS menu select EFTPOS Initialisation.

2. Click Unpair on the EFTPOS Westpac settings screen.


Please visit Harmony for more information.

1. Launch the Assembly Payments Adaptor
2. Go to EFTPOS tab
3. Enter valid POSID and EFTPOS Address
4. Initiate the pairing from the EFTPOS terminal
5. Click the Pair button from the Assembly Payments Adaptor
6. Accept the pairing code on the EFTPOS terminal
7. Pairing Successful.

Please visit Gap Solutions for more information.

1. Launch the Assembly Payments Adaptor
2. Go to Settings tab
3. Select Unpair
4. Unpairing Successful.

Please visit Gap Solutions for more information.

1. Once logged in, you will automatically be directed to the Dashboard
2. On the side panel menu, click Store setup then click Payment types
3. Click ADD PAYMENT TYPE
4. For the payment name, you may put Westpac and for the payment type select Westpac Group Payment
5. Click SAVE and you should be back on the Payment types screen
6. Click on the Configuration Required link
7. Type the POS ID, EFTPOS S/N, EFTPOS Address (Auto IP Resolution should be ticked)
8. Once all necessary fields are filled out, click SAVE, then initiate the Pairing from EFTPOS followed by clicking PAIR button on the POS
9. Confirm that Codes match in both EFTPOS and POS
10. Click OK once pairing is confirmed completed

Please visit Hike for more information.

1. On the side panel menu, click Store setup then click Payment types
2. Click configured link
3. Click UNPAIR button within Westpac Group Settings window.

Please visit Hike for more information.

1. From the main Point of Sale screen click on the Manager button in the bottom left
2. Enter a valid password and select a user
3. Click on the Presto button
4. Click on menu, and then select the pair option
5. Enter a valid POS ID, Terminal Serial Number and Terminal IP
6. (Optional step) Select the Auto Address and Secure Websockets checkboxes if pairing using https and auto address resolution. Ensure test mode is not selected.
7. Initiate pairing on the EFTPOS terminal
8. Click on menu, and then select the pair option. Then click on the Pair button.

Please visit Imagatec for more information.

1. From the main Point of Sale screen click on the Manager button in the bottom left

2. Enter a valid password and select a user
3. Click on the Presto button
4. Click on menu, and then select the pair option
5. Click on the Unpair button
6. Accept codes on both ends if they match.

Please visit Imagatec for more information.

1. Launch the Spice Payments Adaptor.
2. Go to EFTPOS tab.
3. Enter the POSID and EFTPOS Address.
4. Initiate the pairing from the EFTPOS terminal.
5. Click the Pair button from the Spice Payments Adaptor.
6. Accept the pairing code on the EFTPOS terminal.

Please visit IT Visions for more information.

1. Launch the Spice Payments Adaptor.
2. Go to Settings tab.
3. Select Unpair.

Please visit IT Visions for more information.

1. Click on the Admin tab in the top navigation
2. Click on Card link in the side navigation
3. Enter a POS ID, Eftpos address and click on the save button
4. Click OK to acknowledge the prompt
5. Click Pair on the Eftpos terminal
6. Click Pair on the Card Link screen on the PO
7. Accept codes on both ends if they match.


Please visit kitomba for more information.

1. Click on the Admin tab in the top navigation
2. Click on Card Link in the side navigation
3. Click Unpair on the Card Link screen.


Please visit kitomba for more information.

1. Log into the Kounta (application/app)
2. Connect to the register and navigate to the POS application with valid credentials
3. Click on Add-ons
4. Select Pair Westpac Device option
5. Click on Unpair option.



Please visit Kounta by Lightspeed for more information.

1. Select Main Menu (press alt)
2. Select Eftpos (Press E)
3. Select Pair Device
4. Enter the eftpos IP address
5. Select Pair on the Eftpos terminal
6. Select Pair on the POS
7. Wait until a pairing code is displayed on both terminals and if they match select Yes on both.
8. Press Okay to complete the pairing.

Please visit magentaretail for more information.

1. Select Main Menu (press alt)
2. Select Eftpos (Press E)
3. Select Pair Device
4. Select Unpair.

Please visit magentaretail for more information.

1. Select EFTPOS and Pair Terminal.
2. Enter your admin User ID.
3. Enter the EFTPOS IP address.
4. Accept the pairing code.

Please visit Magenta Enabler POS for more information.

1. Select Eftpos
2. Select Unpair.

Please visit Magenta Enabler POS for more information.

1. In the POS, select Pair Device.
2. Enter the POSID and EFTPOS Address and select Save.
3. Initiate pairing from the EFTPOS terminal and POS.
4. Accept the pairing code.

Please visit MAX Pay Global for more information.

1. In the POS, select Pair Device.
2. Select Unpair.

Please visit MAX Pay Global for more information.

Pairing is initiated through the Spice Payments Adaptor. It is important to check if Spice is installed and not the Assembly Payments Adaptor.

1. Launch the Spice Payments Adaptor

2. Go to Status tab
3. Enter valid POS ID and EFTPOS IP Address
4. Initiate the pairing from the EFTPOS terminal
5. Click the Pair button from the Spice Payments Adaptor
6. Accept the pairing code on the EFTPOS terminal
7. Pairing Successful

Please visit Megabus (Marlin GTX) for more information.

1. Launch the Spice Payments Adaptor
2. Go to Settings tab
3. Select EFTPOS Terminal on left pane
4. Select "Unpair Terminal"
5. Unpairing Successful

Please visit Megabus (Marlin GTX) for more information.

1. From the Tools menu click Maintain Terminals
2. Enter the Admin password
3. In the Administrator column select Assembly Payments from the drop down, then click on the ... (dots)
4. (Optional Step) Select the Does the Terminal have an Internal Printer checkbox, and then Use Terminal to Prompt and Print Customer Receipt to print from the VX690 terminal
5. Click on the Pair button on the EFTPOS Terminal
6. Click the Pair button in the EFTPOS Settings popup
7. Accept codes on both ends if they match
8. Once paired, press Close.

Please visit Merlin Software for more information.

1. From the Tools menu click on Maintain Terminals
2. Enter the Admin password
3. In the Administrator column select Assembly Payments from the drop down, then click on the ... (dots)
4. Click the Unpair button in the Eftpos Settings pop-up.


Please visit Merlin Software for more information.

1. On the main screen click Admin in the top right
2. Click on the blue > button on the left hand side of the screen. This opens the main menu
3. Scroll down the menu and click on Configuration in the System section
4. Click on the Payment Method tab
5. Enter a POS ID and EFTPOS IP Address and click on Save
6. Click Pair on the Eftpos terminal
7. Click Pair on the Payment Methods screen
8. Accept both codes if they match
9. Pairing successful. Note: After pairing Presto with MiPOS for the first time, MiPOS needs a Software restart (Logoff - Exit and Open MiPOS) for the new payment method to apply

Please visit MiPOS for more information.

1. On the main screen click on Admin in the top right
2. Click on the blue > button on the left hand side of the screen. This opens the main menu
3. Scroll down and click on Configuration in the System section
4. Click on the Payment Method tab
5. Click Unpair.


Please visit MiPOS for more information.

1. Go to Settings
2. Navigate to Payment Types
3. Go to Westpac

4. Hit Unpair.

Should the EFTPOS terminal remain paired, press Enter + 3 on the EFTPOS terminal to complete unpairing process.

Please visit Mobi POS for more information.

1. Select Admin and select Pinpad Config.
2. Select your desired EFTPOS pinpad and click Configure Pinpad.
3. Select Unpair.

Please visit Ontempo Store for more information

1. Download and Install SPICE found here: Adapter - mx51 Dev Portal
2. Launch the Spice Payments Adaptor
3. Go to EFTPOS tab
4. Enter SIMPHONY POS Workstation ID as the POSID and valid EFTPOS Address
5. Initiate the pairing from the EFTPOS terminal
6. Click the Pair button from the Spice Payments Adaptor
7. Accept the pairing code on the EFTPOS terminal
8. Pairing Successful.


Please visit ORACLE for more information.

1. Launch the Spice Payments Adaptor
2. Go to Settings tab
3. Select "Unpair".

Please visit ORACLE for more information.

1. Launch the POS application.
2. Select Settings and Terminal Setup.
3. Select Unpair.

Please visit OrderBuddy for more information

1. Navigate to File up the top left
2. Select Settings
3. Under ‘Global Settings→EFTPOS’ make sure use EFTPOS is ticked and EFTPOS Type is set to Assembly Payments
4. Expand the local Settings
5. Select EFTPOS
6. Enter in the Eftpos IP Address
7. Select Pair on the Eftpos and POS terminal
8. Wait until a pairing code is displayed on both terminals and if they match select Yes on both.
9. Press Okay to complete the pairing.

Please visit pbsa for more information.

1. Navigate to File up the top left
2. Select Settings
3. Under ‘local settings→EFTPOS’
4. Press unpair.

Please visit pbsa for more information.

1. Log into the Application with valid credentials
2. Click on Back office and then settings
3. In Terminal Settings select Ect
4. Select Pair / Unpair
5. Enter valid POS ID and EFTPOS Address details save and pair.

Please visit POSWAY for more information.

1. Log into the Application with valid credentials
2. Click on Back office and then settings
3. In Terminal Settings select Ect
4. Select Pair / Unpair
5. Click on Unpair button.

Please visit POSWAY for more information.

1. Go to ACTIVITY
2. Go to SUPERVISOR

3. Go to EFTPOS ADMIN

4. Go to EFTPOS PROGRAM

5. Type the POS ID

6. Type the EFTPOS ID

7. Hit SAVE

8. Hit PAIR (after initiating the pairing process from the EFTPOS)

9. Confirm the code matches on the EFTPOS

10. Hit OK to complete the pairing process on the POS


Please visit POS Works for more information.

1. Go to ACTIVITY

2. Go to SUPERVISOR

3. Go to EFTPOS ADMIN

4. Go to EFTPOS PROGRAM

5. Hit UNPAIR

6. Hit CLOSE to leave the screen


Please visit POS Works for more information.

1. Go to SETTINGS (the cog icon on the top right part of the screen)
2. Go to PAYMENT
3. Hit Open Westpac under Payment Type > Westpac
4. Enter the POS ID and EFTPOS IP then hit SAVE
5. Initiate the pairing process from Terminal (# or hit Pair with POS on the touchpad)
6. Accept and confirm the codes match on both Terminal and POS
7. Complete the pairing process

Please visit Remote POS for more information

1. Go to SETTINGS (the cog icon on the top right part of the screen)
2. Go to PAYMENT
3. Hit Open Westpac under Payment Type > Westpac
4. Hit UNPAIR.

Please visit Remote POS for more information.

1. Launch the Spice Payments Adaptor.
2. Go to EFTPOS tab.
3. Enter the POSID and EFTPOS Address.
4. Initiate the pairing from the EFTPOS terminal.
5. Click the Pair button from the Spice Payments Adaptor.
6. Accept the pairing code on the EFTPOS terminal.

Please visit Retail Buddy for more information

1. Launch the Spice Payments Adaptor.
2. Go to Settings tab.
3. Select Unpair.

Please visit Retail Buddy for more information

1. In the POS, select Pair Device.
2. Enter the POSID and EFTPOS Address and select Save.
3. Initiate pairing from the EFTPOS terminal and POS.
4. Accept the pairing code.

Please visit Retail Management Hero for more information

1. In the POS, select Pair Device.
2. Select Unpair.

Please visit Retail Management Hero for more information

1. In the POS, select System Maintenance and Pin Pad Config.
2. Enter the POSID and EFTPOS Address and select Save.
3. Initiate pairing from the EFTPOS terminal and then from the POS.
4. Accept the pairing code.

Please visit Seams Systems for more information

1. In the POS, select System Maintenance and Pin Pad Config.
2. Select Unpair.

Please visit Seams Systems for more information

1. Launch the POS, this will automatically launch the Connector.

2. Click on the Pair button in the Connector, this will display the Westpac Group Settings screen.

3. Enter the POS ID, EFTPOS Address and click on save.

4. Click on the Pair button on the EFTPOS Terminal.

5. Click on the Pair button on the POS.

6. Accept codes on both ends if they match.


Please visit Solemate for more information.

1. Access the History screen.

2. Click on the Westpac logo.

3. Click on the Unpair button on main Connector screen.

4. Click on the Unpair button on the Westpac Group Settings screen.

5. Unpair on the EFTPOS terminal.


Please visit Solemate for more information.

1. Select Login button
2. Select manager name
3. Select tools
4. Select device setup
5. Select EFT
6. Select Configure
7. Select checkbox for touch Keypad then click on the EFTPOS address field
8. Enter IP address from the EFTPOS terminal > Enter > save > Pair
9. Confirm code.

Please visit Starrtec for more information.

1. Select Login button
2. Select manager name
3. Select tools
4. Select device setup
5. Select EFT
6. Select Configure
7. Select Unpair.

Please visit Starrtec for more information.

1. Double click on the installed SwiftPOS Touch application
2. Click on Tools Menu
3. Select option 2 Terminal Settings on Basic Tools
4. Select Peripheral List
5. As a once off activity click on Add New and select Peripheral Type as EFTPOS and enter Description and click on OK
6. .Select the Peripherals and Devices Type which was just added and click on Edit
7. Select EFTPOS Type as EFT26 – Westpac
8. Click on Configuration tab
9. Enter EFTPOS ID and click on Pair button and select Yes on the popup to start the pairing process on the PINPAD
10. Accept Pairing code on the both EFTPOS terminal and POS
11. Click on OK button once status change to "Paired and Connected"
12. Click on Save button twice to save the settings and come out of the Tools Menu.


Please visit SwiftPOS for more information.

1. Double click on the installed SwiftPOS Touch application
2. Click on Tools Menu
3. Select option 2 Terminal Settings on Basic Tools
4. Select Peripheral List
5. Select EFTPOS and click on Edit button
6. Select Configuration button
7. The existing status should be "Paired and Connected", Click on Unpair and select Ok in Unpairing complete popup
8. Click on OK and save button twice to come out of the Tools menu.


Please visit SwiftPOS for more information.
